Carriage inner dimension（mm） 4000x 1500x 220
Rated weight（kg） 2000
Dead weight（kg） 700
Height of Platform（mm）500
climbing angle : less than 14 degree
jack wheel
Warning marks
No galvanized, pickling and parkerising
GPPC 2.5
| Model | GPPC 2.5 |
| Rated weight（kg） | 2000 |
| Dead weight（kg） | 700 |
| Carriage inner dimension Length*width*height（mm） |
4000x 1500x 220 |
| Carriage volume（m³） | 1.8 |
| Axle | torque force axle（RockerSuspension） |
| Specification of tire | TL205/70R14 High-speed tires |
| Brake pattern | Electric brake, hand brake |
| Height of Platform（mm） | 500 |
| Matched tractor | 12/25 |
| Wheel number | 4 |
| superficial treatment | Painting |
long-distance travelling, such as vehicles, defective vehicles, engineering machinery,etc.
Completely configure, it runs steadily. the outlook is artistic, durable in use,
working environment is widespread.
The foldaway crawl ladder for the rear design will be advantageous for the loading .
It can match with all kinds of vehicles ,such as automobiles, tractors and so on .
The form of damping: torque force axle or spring leaf
The form of traction: tripod stand traction(cusion spring)
Manual shaking lifter is the front part design.
The chosen brake is mechanical , handbrake , air brake, oil brake and electronic brake.
Surface treatment: derusting with large size shot blast machine, to change welding stress,
antirusting paint, finishing paint, acid pickling, hot dipping.
The process of welding: carbon dioxide MIG welding.
The form of transportation: parts and components.
The loading capacity is 2-5tons , we can provide tyres according to the carrying capacity.
