GTJZ 0608
GTJZ 0608

Platform height 6.1m
Working height 8.1m
Platform Extention 0.9m
Payload 320kg
AC Power
Options available for:
4*225Ah Battery
Platform AC power
Caution light
Conductive strip
Leakage protection

GTJZ 0608

  • Models
    GTJZ0608

    mobile scissor lift

    6m mobile scissor lift
    Dimensions
     Platform height max.
    21 ft (6.3 m)
    Working height max.
    27 ft (8.3 m)
     Platform extended
    3 ft (0.9 m)
     Length - stowed
    7 ft 8 in (2.39 m)
    Width - stowed
    2 ft 7 in (0.81 m)
     Height -  folding guardrails
    7 ft 3 in (2.22 m)
    Height - rails folded
    6 ft (1.83 m)
    Height - fixed rails
    7 ft 3 in (2.22 m)
     Wheelbase
    6 ft (1.85 m)
    Ground clearance
    3 in (0.1 m)
    Platform size (L*W*H)
    7 ft 4 in*2 ft 7 in*3 ft 6 in (2.25 m*0.81 m*1.1 m)
    Productivity
    Max. platform occupancy
    2 (indoor) 1 (outdoor)
    Lift capacity
    838 lbs (380 kg)
    Lift capacity - extension deck
    265 lbs (120 kg)
    Drive speed - stowed
    0~2.0 mph (0~3.2 km/h)
    Drive speed - raised
    0~0.5 mph (0~0.8 km/h)
    Gradeability
    30%
    Turning radius - inside
    0 ft (0 m)
    Turning radius - outside
    6 ft 9 in (2.1 m)
    Raise / Lower speed
    27/33 s
    Controls
    Proportional
    Drives
    Dual front wheel
    Brakes
    Dual rear wheel
    Tire size (solid non-marking)
    15 in * 5 in (380 mm * 125 mm)
    Power
    Power source
    24V DC (4*6V, 225Ah batteries)
    Hydraulic system capacity
    4.76 gal (18 L)
    Power
    3 KW
    Weight
    Indoor & outdoor general
    3902 lbs (1770 kg)
    Standards Compliance
    CE/ ISO/ ADR/ ARAMCO



Standard technical features Options available
  ●  Self-propelled   ●  Overload sensor with alarm
  ●  Can be drived at full height   ●  AC power on the platform
  ●  Automatic braking system   ●  Platrom work lights
  ●  Proportional controls   ●  Airline to the platfrom
  ●  Automatic pothole protection   ●  4*225Ah Battery
  ●  Self-lock gate on platform   ●  Leakage protection
  ●  Non marking tyre   ●  Portuguese manuals
  ●  Emergency stop button   ●  Portuguese Warning marks
  ●  Emergency lowering system   ●   Onboard diagnostic system
  ●  Cylinder holding valve
  ●  Tilt sensor with alarm
  ●  All Motion Alarm
  ●  Horn
  ●  Hour meter
  ●  Safety brackets
  ●  Forklift pockets
  ●  Foldable guardrails
  ●  Extendable platform
  ●  Charger protection
  ●  Flashing beacon
  ●  2WD

Benefit for the applications:
  ●  Roll-out platform provides spacial-wise workspace
  ●  Folded guardrails helps easy access to narrow doorway at job site or for transportations
      like container or elevator
  ●  7 indoor models are available between working height at 8m to 12m
  ●  Compact design with 0 turn radius facilitates working in confined area
  ●  25% gradeablility for driving on slopes
  ●  Swing-out tray on scissis for easy maintenance
  ●  Portable board diagnosis helps troubleshooting,also making the oprator easier to reset
      the operation conditions
